| Marketing Description |
| The QGD-1600P features SDN, enabling it to function as a NAS, NVR, router, firewall and AP controller for IP surveillance, network security, storage expansion, and wireless LAN management applications. Therefore, the Guardian series offers SMBs a cost-optimized and centrally managed LAN deployment solution. |
| Product Features |
-
Comprehensive layer 2 management features
The QGD-1600P provides comprehensive Layer 2 management features such as VLAN, LACP, and LLDP for you to efficiently control the network through IP grouping and bandwidth management.
-
Dual-system of switch & NAS, enabling optimum performance
The QGD-1600P features dual-system design, multi-port capability and expandable architecture, enabling optimum transmission and flexibility to fulfill business needs in performance and application diversification.
-
One-stop IP surveillance system
The QGD-1600P works seamlessly with your surveillance software service, to help build a cost-effective one-stop IP surveillance system. By integrating PoE, NVR, and NAS storage functions, the QGD-1600P significantly simplifies the surveillance network infrastructure while satisfying the requirements for surveillance deployment, central management, video recording and computing.
|
| General |
| Device Type |
Switch - 16 ports - smart |
| Enclosure Type |
Rack-mountable |
| Subtype |
Gigabit Ethernet |
| Ports |
4 x 10/100/1000 (PoE++) + 10 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP (PoE+) |
| Power Over Ethernet (PoE) |
PoE++ |
| PoE Budget |
370 W |
| Performance |
Non-blocking bandwidth: 16 Gbps
Switching capacity: 32 Gbps |
| MAC Address Table Size |
8K entries |
| Jumbo Frame Support |
9KB |
| Remote Management Protocol |
HTTP, CLI |
| Encryption Algorithm |
FIPS 140-2, 256-bit AES, AES-NI |
| Features |
Flow control, auto-negotiation, trunking, VLAN support, WOL, IGMP snooping, port mirroring, ACL support, LACP support, LLDP support, DHCP client, Energy Efficient Ethernet, loop prevention, SDN, schedule PoE, DNS client, port-based VLAN, port-based QoS, SNTP client, DSCP based QoS, PoE Detection |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt |
| Processor |
1 x Intel Celeron: 1.8 GHz |
| RAM |
4 GB (installed) / 8 GB (max) - SO-DIMM 260-pin - DDR4 SDRAM |
| Flash Memory |
4 GB |
| Built-in Devices |
Status LCD, 2 x 2.5" SATA 6Gb/s drive bays |
| Status Indicators |
PoE, link/activity, speed |
| Expansion / Connectivity |
| Interfaces |
4 x 1000Base-T RJ-45 PoE++ - 60 W
12 x 1000Base-T RJ-45 PoE+ - 30 W
2 x Gigabit LAN SFP
1 x HDMI output
2 x USB 2.0 Type A
1 x USB 3.0 Type A
1 x management (LAN) RJ-45 |
| Expansion Slots |
2 (total) / 2 (free) x PCI Express 2.0 |
| Power |
| Power Device |
Internal power supply |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
418 Watt |
| Miscellaneous |
| Included Accessories |
4 rubber feet, 6 x flat head screws (for 2.5" HDD) |
| Cables Included |
1 x network cable |
| Rack Mounting Kit |
Included |
| Compliant Standards |
VCCI, BSMI, FCC, RCM |
| Software / System Requirements |
| Software Included |
QTS 4.4.1 |
| OS Required |
UNIX, Linux, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Apple MacOS X 10.7 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2016 |
| Dimensions & Weight |
| Weight |
4.41 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
52.8 cm |
| Shipping Depth |
40.3 cm |
| Shipping Height |
16 cm |
| Shipping Weight |
5.56 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 2 years |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
