| Marketing Description |
| The TS-231P3 features a 2.5GbE RJ45 port, providing up to 2.5 times the speed of regular Gigabit Ethernet and enabling smoother multimedia playback and everyday usage. The TS-231P3 ensures data security by supporting AES 256-bit encryption and various local/remote/cloud backup options - including snapshot protection that allows for files and data to be reverted to previously-recorded states if they are accidentally deleted, modified or affected by malware. |
| Product Features |
-
Build a faster home network with QNAP
The TS-231P3 includes a 1GbE port and a 2.5GbE port to provide a smoother NAS experience and multimedia playback. Additional network connection options from QNAP include USB 3.2 Gen 1 to 5GbE adapters (supports N-BASET/Multi-Gig), QXG 5GbE PCIe cards, and QNAP QSW 10GbE switches. All these options allow users to revolutionize their home network at a cost-effective price. The TS-231P3 features three USB 3.2 Gen 1 port that delivers outstanding multitasking performance.
-
Protect important data with snapshots
Snapshots help protect data by fully recording the NAS system state and metadata. With snapshots, users can quickly restore files to previously-recorded states if files are accidentally deleted or modified, or if the system is compromised by malware. QNAP snapshots are block-based and only record modified data. Not only does this save storage space, but also reduces the time required to back up and restore data.
-
Take full control of NAS system status and data security
Notification Center consolidates all QTS system events and alerts, providing a single-app solution for notifications. Security Counselor recommends actions and settings to improve the TS-231P3 security.
-
Comprehensive surveillance solution for 24/7 security
Surveillance Station features a user-friendly interface and supports over 3,000 IP cameras. With an expandable IP camera channel licensing system, users can build a comprehensive surveillance system for real-time monitoring, video and audio recording and playback. Budget-conscious users can also save money on cameras by using USB webcams to record footage. Surveillance feeds can be monitored at any time by using the Vmobile app on mobile devices.
-
Multiply your productivity
The app-driven QTS operating system provides solutions for simplifying file backup, management, search, and more.
|
| General |
| Device Type |
NAS server |
| Host Connectivity |
Gigabit Ethernet |
| Total Storage Capacity |
0 GB |
| Installed Devices / Modules Qty |
0 (installed) / 2 (max) |
| Width |
10.2 cm |
| Depth |
21.9 cm |
| Height |
16.9 cm |
| Weight |
) |
| Built-in Devices |
Status LCD, led panel |
| Processor / Memory |
| Processors Installed |
1 x Annapurna Labs Alpine AL-314 1.7 GHz |
| Number of Cores |
Quad-Core |
| Max Supported Qty |
1 |
| RAM |
2 GB (installed) / 8 GB (supported) - DDR3 |
| Flash Memory Installed |
512 MB |
| Storage Controller |
| Type |
RAID |
| Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 0, RAID 1, JBOD |
| Networking |
| Data Link Protocol |
10Mb LAN, 100Mb LAN, 1GbE |
| Network / Transport Protocol |
TCP/IP, PPTP, L2TP, IPSec, iSCSI, SMTP, FTP, DHCP, Bonjour, SMB, DDNS, SFTP |
| Remote Management Protocol |
SNMP, Telnet, HTTP, HTTPS, TFTP, SSH |
| Network Services Compatibility |
Microsoft Active Directory (AD), Apple Bonjour Protocol, File Level Security (ACLs), DHCP, DDNS, Microsoft CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), SFTP |
| Features |
Trunking, LDAP support, wake on LAN (WOL), Syslog support, manageable, E-mail alert, print server, IPv6 support, 256-bit encryption, proxy server, web server, backup server, download client, event log, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, SSH support, iTunes server, Jumbo Frames support, DHCP server, FTP server, SMS alert, BitTorrent Client, reset button, bandwidth control, IPv4 support, surveillance station, teaming support, DLNA Media Server, Apple Time Machine compatible, DHCP client, cloud backup, VPN Server, SFTP client, SNMP support, Apple AirPlay, Dropbox support, Wi-Fi USB dongle support, Real-time Remote Replication (RTRR), Google Drive support, Amazon Cloud Drive support, Yandex Disk support, Microsoft OneDrive support |
| Encryption Algorithm |
SSL, TLS, 256-bit AES |
| Compliant Standards |
UPnP |
| Expansion / Connectivity |
| Expansion Bays |
2 (total) / 2 (free) x hot-swap - 2.5" / 3.5" |
| Interfaces |
2 x Ethernet 1000Base-T - RJ-45
3 x USB 3.0 - Type A |
| Miscellaneous |
| Cables Included |
1 x network cable |
| Features |
Security lock slot (cable lock sold separately), audible alarm, built-in cooling fan, hardware encryption, scheduled power on/off |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
AES-256 |
| Included Accessories |
12 x flat head screws (for 2.5" HDD), 16 x flat head screws (for 3.5" HDD), power cable |
| Power |
| Power Device |
External power adapter |
| Voltage Required |
AC 120/230 V |
| Power Consumption Operational |
15.6 Watt |
| Power Provided |
65 Watt |
| Software / System Requirements |
| Storage Operating System |
QNAP QTS 4.2 |
| OS Required |
UNIX, Linux, Apple MacOS X, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10 (32/64 bits) |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Sound Emission |
19.5 dBA |
