| Marketing Description |
| The TS-464eU is powered by Intel Celeron N5095/5105 quad-core processor (burst up to 2.9 GHz). The space-efficient short depth design makes it easy to install in small media cabinets or places with a lot of cabling. With expandable storage capacity and feature-rich apps, the TS-464eU surpasses the previous generation. |
| Product Features |
-
2.5GbE connectivity
Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE ports.
-
HDMI Output
Supports 4K media playback and real-time transcoding.
-
NVMe SSD application
Two M.2 PCIe NVMe SSD slots support Qtier auto-tiering technology and SSD caching.
-
USB interface
Two USB 3.2 Gen 2 10Gbps ports for faster data transfer.
-
Backup and data recovery
Protects PC/Macs, virtual machines, software containers, cloud data, and SaaS services.
-
Hybrid cloud applications
Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS.
-
Quad-core Processor, burst up to 2.9 GHz with Memory Upgradable to 8 GB
The TS-464eU is powered by Intel Celeron N5095/N5105 quad-core processor (burst up to 2.9 GHz) with 4 GB DDR4 memory which is upgradable up to 16 GB. With Intel AES-NI encryption engine, the TS-x64eU provides unmatched encryption performance with AES-256 bit encryption acceleration, boosting system performance while ensuring the safety of sensitive business data stored in the NAS.
-
Build a High-Speed 2.5GbE Network Environment
QNAP offers comprehensive, budget-friendly storage and networking solutions that provide an array of connectivity possibilities. Easily and flexibly upgrade your workplace or home network now to handle bandwidth-hungry applications.
-
Future-proof your IT infrastructure for high-speed networks
The TS-464eU is ideally matched with QNAP's managed and unmanaged 2.5GbE/10GbE switches to form high-speed, secure, and scalable network environments without going over budget. QNAP also provide 2.5GbE/5GbE/10GbE PCIe cards and USB 5GbE adapters for Windows /Linux workstations, allowing you to easily build a high-speed network environment for productive team collaboration.
-
Enhance productivity with multiple USB ports
With two USB 3.2 Gen 2 (10Gbps) ports and two USB 2.0 (480Mbps) ports, you can quickly backup and transfer large files to/from the TS-464eU. UPS, printers, and other compatible USB devices can also be connected for greater functionality and application potential.
-
SSD Caching and Auto Tiering for Optimized Storage Efficiency
The TS-464eU supports SSD caching to improve the workflow of random IOPS demanding applications such as virtualization. Qtier Technology empowers the TS-464eU with auto tiering that continuously optimizes storage utilization across high-performance SSD and high-capacity SATA drives. Qtier 2.0 features IO-awareness that empowers SSD tiered storage with a cache-like reserved space to handle burst I/O in real time, greatly maximizing the advantages of SSD.
|
| General |
| Device Type |
NAS server |
| Host Connectivity |
2.5 Gigabit Ethernet |
| Enclosure Type |
Rack-mountable - 1U |
| Total Storage Capacity |
0 GB |
| Installed Devices / Modules Qty |
0 (installed) / 4 (max) |
| Width |
43 cm |
| Depth |
29.5 cm |
| Height |
4.4 cm |
| Weight |
4.15 kg () |
| Processor / Memory |
| Processors Installed |
1 x Intel Celeron |
| Number of Cores |
Quad-Core |
| Max Supported Qty |
1 |
| Max Turbo Speed |
2.9 GHz |
| RAM |
4 GB (installed) / 16 GB (supported) - DDR4 |
| Flash Memory Installed |
4 GB |
| Storage Controller |
| Type |
RAID |
| Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
| Networking |
| Data Link Protocol |
10Mb LAN, 100Mb LAN, 1GbE, 2.5GbE |
| Network / Transport Protocol |
iSCSI, DHCP, SMB, DDNS, IPv4, IPv6 |
| Remote Management Protocol |
SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH |
| Network Services Compatibility |
DHCP, DDNS, Microsoft CIFS, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Network File System v3 (NFS v3), Network File System v4 (NFS v4) |
| Features |
Firewall protection, VPN support, LDAP support, VLAN support, wake on LAN (WOL), anti-malware protection, Access Control List (ACL) support, RADIUS support, Jumbo Frames support, DHCP server, built-in hardware transcoding, file station, port trunking, EXT4 file system, RAID migration, hybrid backup sync, Qfiling, Qsirch, Q'center (NAS CMS), SQL Server, Qsync, QuMagie, QmailAgent, QuWAN |
| Encryption Algorithm |
AES-NI |
| Expansion / Connectivity |
| Expansion Bays |
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots |
2 (total) / 1 (free) x SO-DIMM 260-pin
2 x M.2 2280 |
| Interfaces |
2 x 2.5 Gigabit Ethernet - RJ-45
2 x USB 3.2 Gen 2 - Type A
3 x USB 2.0 - Type A
1 x HDMI output |
| Miscellaneous |
| Cables Included |
1 x network cable |
| Features |
Audible alarm, built-in 3 cooling fans, Secure Erase, dual boot |
| Compliant Standards |
TLS v1.2, TLS v1.0, TLS v1.1, TLS v1.3 |
| Included Accessories |
12 x flat head screws (for 2.5" HDD), 16 x flat head screws (for 3.5" HDD), 2 x hangers, 2 x holders, power cable |
| Power |
| Power Device |
Internal power supply |
| Voltage Required |
AC 100-240 V |
| Power Provided |
100 Watt |
| Software / System Requirements |
| Storage Operating System |
QNAP QTS 5.0.0 |
| Software Included |
IronWolf Health Management |
| OS Required |
Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, SUSE Linux 12.2, Microsoft Windows Server 2016, Apple MacOS X 10.10 or later, CentOS 7.0, Microsoft Windows Server 2019, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11 |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years |
| Dimensions & Weight (Shipping) |
| Shipping Weight |
5.79 kg |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% RH (non-condensing) |
