| Marketing Description |
| Powered by the x86 architecture Zhaoxin KaiXian KX-U6580 8-core processor, the TVS-675 provides businesses with a modern 2.5GbE NAS solution to tackle everyday tasks like file backup/restore, and to boost team collaboration with higher productivity. Besides hardware advantages with built-in M.2 SSD slots for cache acceleration and PCIe expansion, the TVS-675 supports abundant business and media applications (including snapshot protection, virtual machines, cloud storage gateways, 4K HDMI display, and real-time transcoding) alongside expandable storage capacity and install-on-demand apps, making it a cost-effective and reliable data storage and media NAS. |
| Product Features |
-
High-performance multi-tasking with an 8 core 2.5GHz processor and up to 64 GB RAM
Powered by an x86 architecture Zhaoxin KaiXian KX-U6580 8 cores/8 threads 2.5GHz processor and 8 GB DDR4 memory (expandable up to 64 GB - 2x 32GB, dual channel support), the TVS-675 has enormous processing power to drive virtual machine performance and tackle complex multitasking workloads. AES-NI encryption support boosts encryption performance while also maintaining the security of your NAS data.
-
Streamline large file transfers and video editing with 2.5GbE
The TVS-675 comes with two 2.5GbE RJ45 (2.5G/1G/100M) LAN ports that allow you to use existing CAT 5e cables to upgrade network speeds from 1 Gigabit to 2.5 Gigabit. The dual 2.5GbE ports also support Port Trunking for up to 5 Gbps transmission speeds, improving the business efficiency of bandwidth-hungry applications such as large file transfers, fast backup/restoration, and multimedia transfer and editing.
-
Faster USB transfers
Featuring two USB 3.2 Gen 2 (10Gbps) and two USB 3.2 Gen 1 (5Gbps) ports, the TVS-675 allows compatibility with faster USB external drives/enclosures for transferring large media files. The TVS-675 also supports USB devices such as mobile phones, uninterruptible power supplies, and printers for greater all-round functionality.
-
Abundant I/O capabilities with PCIe expansion
The TVS-675 has two PCIe Gen 3 x4 slots that allow for installing various expansion cards for expanding application potential.
|
| General |
| Device Type |
NAS server |
| Host Connectivity |
Gigabit Ethernet / 2.5 Gigabit Ethernet |
| Total Storage Capacity |
0 GB |
| Installed Devices / Modules Qty |
0 (installed) / 6 (max) |
| Width |
26.39 cm |
| Depth |
28.08 cm |
| Height |
18.82 cm |
| Weight |
6.2 kg () |
| Built-in Devices |
Led panel |
| Processor / Memory |
| Processors Installed |
1 x ZhaoXin Kaixian KX-U6580 2.5 GHz |
| Number of Cores |
8-core |
| Max Supported Qty |
1 |
| RAM |
8 GB (installed) / 64 GB (supported) - DDR4 |
| Flash Memory Installed |
5 GB |
| Storage Controller |
| Type |
RAID |
| Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 5, RAID 6, RAID 10 |
| Networking |
| Data Link Protocol |
100Mb LAN, 1GbE, 2.5GbE |
| Network / Transport Protocol |
TCP/IP, IPv4, IPv6, DHCP, DDNS, HTTP, HTTPs, Telnet, SMSC, RTSP, PPTP, L2TP, IPSec |
| Remote Management Protocol |
SNMP 2, SNMP 3, LDAP, SSH, Telnet, HTTP, HTTPS |
| Network Services Compatibility |
Apple File Protocol (AFP), File Level Security (ACLs), FTP, Microsoft CIFS, Network File System v3 (NFS v3), Network File System v4 (NFS v4), Server Message Block (SMB), FTPS, Microsoft Active Directory (AD), HTTP, HTTPS, SFTP, DDNS, DHCP |
| Features |
EXT4 file system, NAT support, Spanning Tree Protocol (STP) support, online RAID capacity expansion, online RAID level migration, SSD trim, iSCSI LUN clone/snapshot, snapshot (folder and LUN), iSCSI Extensions over RDMA (iSER), iSCSI initiator, VJBOD Cloud, WebDAV server support, built-in hardware transcoding, Syslog support, file station, LDAP support, SMS alert, push notification, myQNAPcloud, e-mail notification, wake on LAN (WOL), network monitoring, Performance Monitoring, Qsync, Qsirch, file sharing, Qfiling, hybrid backup sync, Amazon Glacier suport, Amazon S3 support, OpenStack Swift-compatible, Alibaba Cloud OSS support, Amazon Cloud Drive support, Backblaze B2 support, Dropbox support, HiDrive support, hubiC support, Microsoft OneDrive support, Yandex Disk support, RTRR server, RTRR client, Rsync compatible, Apple Time Machine compatible, QuMagie, WebRTC, ONVIF support, OpenVPN pass-through, Q'center (NAS CMS), Chromecast support, BitTorrent Client, Qcontactz, IFTTT agent, Qmiix agent, Qfinder Pro |
| Encryption Algorithm |
SSL, TLS, 256-bit AES, FIPS 140-2 |
| Compliant Standards |
UPnP, DLNA CERTIFIED |
| Expansion / Connectivity |
| Expansion Bays |
6 (total) / 6 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots |
2 (total) / 2 (free) x M.2 2280
2 (total) / 2 (free) x PCI Express 3.0 x4 |
| Interfaces |
2 x 2.5 Gigabit Ethernet - RJ-45
2 x USB 3.2 Gen 1 - Type A
2 x USB 3.2 Gen 2 - Type A
1 x HDMI output - Type A |
| Miscellaneous |
| Cables Included |
1 x network cable |
| Features |
Security lock slot (cable lock sold separately) |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
FIPS 140-2, TLS v1.0, TLS v1.1, TLS v1.2, SSL |
| Included Accessories |
2 x M.2 SSD heatsink, 18 x flat head screws (for 2.5" HDD), 18 x flat head screws (for 3.5" HDD), 2 x hard drive security key, power cable |
| Power |
| Power Device |
Internal power supply |
| Voltage Required |
AC 120/230 V |
| Power Consumption Operational |
60.794 Watt |
| Power Consumption Stand by |
41.897 Watt |
| Power Provided |
250 Watt |
| Software / System Requirements |
| Storage Operating System |
QNAP QTS hero |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 2 years |
| Dimensions & Weight (Shipping) |
| Shipping Weight |
7.67 kg |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Sound Emission |
20.2 dBA |
