| Marketing Description |
| Samsung's OMN Series was designed with a storefront window display in mind. It projects clear, bright images so you can attract and engage your audience. The display has a slim design and is compatible with virtually any store window. Plus, an embedded software solution offers operational efficiency and content management, helping you to manage your displays effortlessly. |
| Product Features |
-
Bright, brilliant picture quality
At 4,000 nits, messages remain bright and clear even in direct sunlight in a storefront. Combined with a high 5,000:1 contrast ratio, you get an uncompromised picture that can capture customers' attention and entice them into your store.
-
Designed for storefront window displays
A remarkably slim design lets you easily mount the OMN Series on a stand or hang it from a ceiling. So you have more options for positioning, giving you flexibility in how valuable space on your floor is designed and utilized. The clean look of the display allows for customer engagement without aesthetic distraction.
-
All-in-one digital signage solution
The embedded MagicInfo Player S6, backed by the powerful Tizen operating system, boosts the display's performance, allows for easy content management and helps to ensure seamless content transition and playback. All without the need for an external signage player or PC.
-
Samsung circular polarizing technology
Samsung's circular polarizing technology allows content to be easily viewed even while wearing polarized sunglasses.
-
Commercial reliability
Built to handle 24/7 continuous operation with IP5X-validated dust protection and engineering to prevent damage from overheating, you'll be able to deliver impactful messaging to your audience around the clock.
-
Built-in Wi-Fi and clutter-free cable management
The cable guide and embedded Wi-Fi allow for a clean, organized look plus the ability to perform content and firmware updates without the need for additional cables.
|
| General |
| Product Type |
LED-backlit LCD flat panel display |
| Energy Class |
Class G |
| Power Consumption Operational |
450 Watt |
| Power Consumption (On mode) |
276 W |
| Power Consumption SDR (On mode) |
276 kWh/1000h |
| Diagonal Class |
55" |
| Commercial Use |
Yes - digital signage |
| Platform |
Tizen OS |
| Operating System |
Tizen OS 4.0 |
| TV Tuner Presence |
No |
| Sensors |
Temperature sensor, ambient brightness sensor |
| Video Interface |
HDMI |
| HDMI Ports Qty |
2 ports |
| PC Interface |
DisplayPort |
| Width |
125.34 cm |
| Depth |
5.45 cm |
| Height |
72.42 cm |
| Weight |
23.1 kg |
| Display |
| Resolution |
1920 x 1080 |
| Image Aspect Ratio |
16:9 |
| LCD Backlight Technology |
Edge-lit LED |
| Image Contrast Ratio |
4000:1 |
| Dynamic Contrast Ratio |
100000:1 |
| Brightness |
4000 cd/m² |
| Viewing Angle |
178 degrees |
| Viewing Angle (Vertical) |
178 degrees |
| Response Time |
6 ms |
| Commercial Features |
Auto Source Switching & Recovery, Lamp Error Detection, Clock Back Up Supply, MagicInfo Player, Visible with Polarised Sunglasses |
| Features |
Multiple Display Control (MDC), MagicInfo Videowall-S, Auto Brightness Control, SSSP 6.0 |
| Stands & Mounts |
| Stand |
Optional |
| Flat Panel Mount Interface |
400 x 400 mm |
| VESA Compatibility |
Yes |
| Media Player |
| Supported Video Formats |
MPEG-1, MPEG-2, MPEG-4, AVC, H.264, H.263, VC-1, HEVC, MPEG, VP9, VP8, AVS+ |
| Supported Audio Formats |
MP3 |
| Supported Pictures Formats |
JPG, PNG |
| USB Port |
Yes |
| USB Ports Qty |
1 |
| Configuration |
ARM Cortex-A72 Quad-Core ( 1.7 GHz ) - 2.5 GB LPDDR4 - 8 GB |
| Storage Drive Capacity |
8 GB |
| Remote Control |
| Type |
Remote control |
| Network & Internet Multimedia |
| Functionality |
Digital audio playback, digital photo playback, digital video playback |
| Connectivity |
LAN |
| LAN Protocol |
Ethernet |
| Connections |
| Connector Type |
DisplayPort input
2 x HDMI input
USB 2.0
HDMI output
Audio line-out
RS-232C
LAN |
| Miscellaneous |
| Included Accessories |
Batteries, ambient light sensor kit |
| Cables Included |
IR receiver cable |
| Compliant Standards |
EMC Class A, cUL No.60950-1, IP5X, EN60950-1:2001, IEC60950-1, EN55022:2006 + A1:2007 Class A, FCC Subpart B 15.107, EN 55024:1998+A1:2001+A2:2003 |
| Power |
| Power Device |
Power supply |
| Input Voltage |
AC 120/230 V (50/60 Hz) |
| Power Consumption Stand by |
0.5 Watt |
| Power Consumption Sleep |
0.5 Watt |
| Power Consumption (Off Mode) |
0.5 Watt |
| Dimensions & Weight (Shipping) |
| Width (Shipping) |
142 cm |
| Depth (Shipping) |
17.8 cm |
| Height (Shipping) |
87.9 cm |
| Weight (Shipping) |
29.1 kg |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
10 - 80% (non-condensing) |
